Gigabit ODU Wifi 5g Lte Router POE 48V Power Ethernet LAN Port 5g Router Wireless
Product Description
The 5G ODU Outdoor CPE is an easy-to-deploy, high performance 5G/LTE CPE features a dedicated 2.5Gigabit Ethernet port and 5G/LTE mobile broadband for maximum redundancy and flexibility for intense Internet applications in remote areas. Rugged design and flexible deployment options combined with ease of use make the 5G ODU ideal for both large-scale and individual deployment
Connectivity Where You Need It Most
Easily connect to your high-speed 5G/LTE mobile service with the 5G ODU Outdoor CPE and enjoy fast 5G/LTE downlink speeds, giving you speed you need for fast, responsive Internet access. The blazing fast 5G/LTE connection allows multiple users to access e-mail and stream music and video. Directional antennas allow it to be installed in areas underserved by traditional broadband networks and often at the edge of mobile networks.
Product Highlights
Specification
General | |
Device Interfaces |
• 1x 2.5G bps GE Ethernet port • 6xLED indicator PWR,LAN,5G, Signal Strength LEDs*3 • 1.8V SIM card slot (2FF) • Reset button |
Standards |
• IEEE 802.3i 10Base Ethernet • IEEE 802.3u Fast Ethernet • IEEE 802.3ab Gigabit Ethernet • IEEE 802.3bz 2.5Gigabit Ethernet • IEEE 802.3af 12.95W POE |
5G/ LTE chipset | • Qualcomm SDX55 |
5G/ LTE Standards |
• Release 15, Cat.16 • 5G NR |
5G/ LTE Frequency Support |
• 5G NR SA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78/n79 • 5G NR NSA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78/n79 • LTE FDD: B1/B3/B5/B7/B8/B18/B19/B20/B26/B28/B32 • LTE TDD: B34/B38/39/B40/B41/B42/B43 |
5G/LTE Throughput |
• 5G SA Sub-6 : DL 2.1Gbps; UL 900Mbps • 5G NSA Sub-6: DL 2.5Gbps; UL 650Mbps • LTE: DL 1.0Gbps; UL 200Mbps |
MIMO | • DL: 4 × 4 UL: 2 × 2(only support 5G SA) |
Output Power | • 23dBm±2dBm |
Antenna | • 8dBi Internal omni antenna |
Device Management | |
• HTTPS Management Interfaces • Standard Based TR-069 Management • HTTP OTA Firmware Upgrade • USIM and Network PLMN Locking Support • Device Factory Default Setting |
|
Networking Configuration | |
• DHCP IP address Assignment • Router Operation Support • Built-in DHCP Server for LAN Devices • IPv4, IPv6 DS - Lite Support • NTP Service Support • SIM card locking feature • Network selection and cell locking provision |
|
Physical | |
Dimensions | • 330(H)X250(W)X85(D)mm |
Weight | • <3Kg |
Enclosure | • IP 65 |
Power protection | • +- 6kV |
Power | • 48V Power over Ethernet |
Power Consumption | • < 10W |
Temperature |
• Operating: -30 to 75 °C • Storage: -40 to 85 °C |
Humidity | • 10 % to 95 % non-condensing |
Certifications | • CE FCC |
Details Images
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 1-3 working days, mass production time needs 3-5 weeks based on order quantity.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. Do your products meet our standards?
A: Yes, almost all our products have CE,ROHS,FCC,etc.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Then we arrange the production.
