Gigabit Port 1800Mbps Wifi 6 Wireless Router Linux OpenWRT System

Gigabit Port 1800Mbps Wifi 6 Wireless Router Linux OpenWRT System

  • High Light

    Gigabit Port Wifi 6 Wireless Router


    Wifi 6 Wireless Router Linux OpenWRT

  • User
    128 Wireless Users
  • System
    Linux. OpenWRT Version
  • Wireless Speed
  • Interface
  • Flash
    16MB SPI
  • RAM
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 piece
  • Price
  • Packaging Details
    28*28*6 cm 1piece
  • Delivery Time
    7 work days
  • Payment Terms
    T/T, Western Union,Paypal
  • Supply Ability
    1000PCS/45 days

Gigabit Port 1800Mbps Wifi 6 Wireless Router Linux OpenWRT System

5g Wifi6 AX1800 Smart Dual Band Router Gigabit Port 1800Mbps Wireless Router


Product Description

   Ma220 is a high-performance enterprise WiFi 6 router product supporting 802.11ax technology. It works in 2.4G & 5.8G wireless frequency band and meets the needs of 128 people accessing the Internet wirelessly at high speed at the same time. Full gigabit network interface, 2.4G 802.11ax mode can support up to 573mbps wireless access speed, 5.8G 802.11ax mode can support up to 1201mbps wireless access speed. With the characteristics of high performance, high gain, high receiving sensitivity, high bandwidth and high access number, it can not only cover a wider range, but also provide higher wireless transmission performance and stability. Fashionable appearance design, simple and convenient installation, it is the best choice for wireless access in high-density environment such as home, shop, restaurant and enterprise.



High performance hardware configuration
  It adopts mt7621 + mt7905 + mt7975 high performance SOC suite, with 16MB flash memory and 256MB memory, industrial grade circuit design, supports ieee802.11a/b/g/n/ac/ax protocol, and can provide 2.4G 573mbps + 5.8G 1201mbps wireless access speed and 1000Mbps Ethernet switching processing speed. The whole machine can provide up to 1800mbps wireless access speed. Ultra high speed wireless makes performance no longer a bottleneck. Enhanced cooling and air duct optimization make the hot summer no longer cause downtime, fully guarantee the real-time, long-term, stable and efficient transmission of user network data, and improve the user experience.


Combined with the hardware and software optimization of Hnat, the wired bidirectional forwarding performance can reach 2gbps, which greatly improves the data forwarding ability of the device, ensures the real-time linear forwarding of user data, reduces the network delay, and improves the network transmission efficiency and user experience.


It adopts dual channel and dual band design, 2.4G & 5.8G adopt the latest WiFi wireless standard - 802.3ax protocol, the maximum connection rate of 2.4G wireless band can reach 573mbps, and the maximum connection rate of 5.8G band can reach 1201mbps; when dual band is turned on at the same time, it can provide 1800mbps wireless access speed, providing ultra high speed wireless experience.



  The wave velocity shaping technology can automatically adjust the signal weighting value of each element in the array when the interference direction is unknown, so that the zero point of the antenna pattern is aligned with the interference direction to suppress the interference, enhance the detection ability of the system's useful signal, optimize the antenna pattern, and effectively track the useful signal, suppress and eliminate the interference and noise, even in the short range The interference can also be suppressed successfully when the distributed interference and the signal have the same frequency.





Product parameters
Main chip MT7621A+MT7905DAN+MT7975DN
Main frequency Dual core four thread 880MHz
Wireless technology

2.4G WiFi 2 * 2 802.11b/g/n/ax (theoretical maximum speed up to 573mbps)

5.8G WiFi 2 * 2 802.11a/n/ac/ax (theoretical maximum speed up to 1201mbps)

1024qam ultra high speed access rate, OFDMA ultra high density user access

MU-MIMO / mu-ofdma uplink / downlink

BSS color space reuse

Space time block code (STBC), low density parity check (LDPC), beamformer TX / RX

Energy saving: single antenna standby technology, dynamic MIMO power saving technology, enhanced automatic power saving transmission technology, packet by packet power control technology, etc

Memory 256MB DDR3 RAM
Flash 16MB
network interface 4*10/100/1000Mbps,1WAN+3LAN

1 * reset button, long press for 6 seconds to restart, long press for more than 6 seconds to restore factory settings

1 * power button to control the power switch of the equipment

1 * WPS button for easy interconnection without password

indicator light System status indicator
Power Supply DC 12V 1A,﹤12W
work environment

Temperature: - 40 ℃ ~ + 55 ℃ (working), - 40 ℃ ~ + 70 ℃ (storage)

Humidity (non condensing): 5% - 90% (working), 5% - 95% (storage)


2 external 2.4G high gain 5dBi omnidirectional antennas * 2

2 external 5.8G high gain 5dBi omnidirectional antennas * 2


Details Images

Gigabit Port 1800Mbps Wifi 6 Wireless Router Linux OpenWRT System 0Gigabit Port 1800Mbps Wifi 6 Wireless Router Linux OpenWRT System 1Gigabit Port 1800Mbps Wifi 6 Wireless Router Linux OpenWRT System 2
