4g Lte Router DC 9-48V Supply 300Mbps 4g Wifi Router With RS232/485 Serial Port
Product Description
WR200 is a high-performance Wi Fi all network 4G wireless industrial router tailored for the Industrial internet of things scenario. It integrates 4G LTE, 802.11b/g/n 300M Wi Fi, eSIM/external SIM card software switching, 10/100M adaptive Ethernet interface (4LAN and 1WAN/LAN), 485/232 serial port, 48V PoE WAN, DC 9-48V wide voltage input, IoT platform access, Ali Iot MQTT access, 485 transparent transmission, VPN and Tr069 platform centralized management, etc. Provide advanced internet connectivity and high-speed data access for devices, while helping enterprise customers achieve efficient large-scale network deployment and management.
Fully industrial design, stable and reliable
Designed with fully industrial components and metal casing, with a protection level of up to IP30; Supports wide voltage DC 9-48V wide voltage input and has power reverse protection function; Support multiple protections such as static electricity, surge, and fast electrical pulse trains; Built in software and hardware watchdog for fault self detection and self repair, ensuring long-term stable operation of the system; Adapted to various harsh industrial environments, it can operate stably and reliably for a long time without the need for manual intervention.
Rich interfaces and strong scalability
Supports RS232&RS485 serial port device access and data transmission, making it easy to connect various serial port devices to internet servers and achieve real-time data monitoring.
Free VPN support for remote network resource sharing
Support PPTP and L2TP VPN client connection methods, establish a dedicated network on the public network, achieve interconnection between devices on the public network, meet various needs of users for remote access to internal network resources, and achieve remote network resource sharing.
Multiple status statistics, constantly aware of equipment working status
Built in traffic statistics, supporting traffic package settings, easy to understand monthly traffic usage; Multi state work indicator light, real-time work log viewing, constantly understanding the equipment's working status.
Specification
| Product parameters | |
| hardware configuration | |
| Main chip |
MTK7628NN High performance enterprise grade chips |
| Main frequency | 880MHz |
| Wireless technology | 802.11b/g/n 300M MIMOtechnology; |
| Flash memory | 16MB |
| Memory | 128MB |
|
Device interface
|
WAN 10/100/100Mbps Adaptive network interface *1 LAN 10/100/100Mbps adaptive network interface * 4 RS232/485 serial port Stand SIM card, large card Ground wire interface |
| Antenna |
External 2.4G 5dBi stick antenna * 2 External 4G 5dBi stick antenna * 2 |
| Power supply | DC 9-48V/Phoenix terminal,48V PoE |
| Keys | 1 RESET reset button, press and hold for 5 seconds to Factory reset |
| Indicator light |
PWR,SYS,WiFi,4G,Ethernet port indicator light
|
| Size/Weight | N/A |
| Working/Storage Temperature | -40℃~45℃/-20℃~70℃ |
| Working/Storage Humidity | 5%~95%(non-condensing) |
