300Mbps Mobile Router 4g Wifi Chip MTK7621A 4g Wifi Router With Sim Card Slot
Product Description
HUASIFEI HR204 wireless router is a wireless communication product developed based on 4G network requirements. Support 4G LTE global frequency band. Support 4G LTE CAT 6 or CAT 12 high speed access to the Internet. It can realize the maximum downlink bandwidth of 300Mbps~600Mbps and the maximum uplink bandwidth of 50Mbps~150Mbps. It supports 2 Gigabit Ethernet ports, providing stable and high-speed wireless broadband access for home and business users. Support for WIFI 2.4GHz/5GHz dual-band function to meet the access and sharing needs of more than 60 users' WIFI hotspots.
Product features
Easy to use and easy maintenance
Operating system
Built-in OpenWRT 18.06 operating system. Support user secondary application development.
Specification
| Cellular feature | |
|
3G/4G LTE data connectivity |
It provides data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA networks. |
|
3G/4G LTE Frequency bands |
Version E. LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 LTE-TDD: B38/B40/B41/B42(Optional) /B43(Optional) WCDMA: B1/B3/B5/B8 Verison A. LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B25/B26/B29/B30/B66/B71 LTE-TDD: B41/B48 Version LA. LTE-FDD: B2/B4/B5/B7/B8/B28/B66 LTE-TDD: B42(Optional) /B43(Optional) WCDMA: B2/B4/B5/B8
Remarks. More Bands Demands please contact with us. |
| 3G/4G LTE Data rates |
4G LTE--CAT 6 LTE-FDD Max 300M(DL) , Max 50Mbps (UL) LTE-TDD Max 226M (DL) , Max 28Mbps (UL).
4G LTE-CAT 12 LTE-FDD. Max 600Mbps (DL),Max 150Mbps (UL) . LTE-TDD. Max 430Mbps (DL),Max 90Mbps (UL).
HSPA+. DL 42Mbps, UL 11.2Mbps.
WCDMA. DL 384Kbps, UL 384Kbps |
|
3G/4G LTE Transmitting Power |
Class 3 (23 dBm±2 dB) for LTE-TDD bands Class 3 (23 dBm±2 dB) for LTE-FDD bands Class 3 (24 dBm+ 1/-3 dB) for WCDMA bands |
| LTE features |
CAT 6 version. Supports 3GPP Rel-12 CAT 6 FDD and TDD Supports uplink QPSK and 16 QAM modulation. Supports downlink QPSK , 16 QAM and 64 QAM. Supports 1.4MHz to 40MHz (2 CA) RF bandwidth.
CAT 12 version. Supports 3GPPRel-12 CAT 12 FDD and TDD. Supports uplink QPSK ,16 QAM and 64 QAM modulation. Supports downlink QPSK , 16 QAM ,64 QAM and 256 QAM. Supports 1.4MHz to 60MHz (3 CA) RF bandwidth. |
| UMTS features |
Supports 3GPP Rel-9 DC-HSDPA,DC-HSUPA,HSPA+,HSDPA,HSUPA and WACDMA Supports QPSK ,16 QAM and 64 QAM modulation. |
| Antennas | Supports 2*2 MIMO or 4*4 MIMO internal antenna or external antenna with 50 Ω impedance. |
| SIM card feature | |
| SIM card | Supports 1* SIM slots, 1.8V / 3V . Or 1* eSIM card. ( Optional ) |
Details Images
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 1-3 working days, mass production time needs 3-5 weeks based on order quantity.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. Do your products meet our standards?
A: Yes, almost all our products have CE,ROHS,FCC,etc.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Then we arrange the production.
Our products are sold all over the world, you can rest assured.
