3000Mbps Wifi6 Router Chip MT7981B+ UNISOC V510 5g Lte Wifi Router With Sim Slot

3000Mbps Wifi6 Router Chip MT7981B+ UNISOC V510 Wifi Router 5g Lte With Sim Slot

Product Description

5G & WiFi-6 Smart Router System (CPE), is based on brand-new embed platform, it can be satisfied with growing-up mobile connections requirements and provides the fast speed beyond your imagination.

The CPE is compatible with NSA/SA dual-mode, suits to all network types all over the world, it means you just plug and play it and enjoy the ultra-fast broadband connection at any places.

The CPE brings the new way to enable you experience VR/AR/4K/8K streaming freely and easily. With 802.11ax (Wi-Fi 6) technology built-in, the single CPE has wider wireless coverage and more bandwidth. Meanwhile the CPE brings higher security, better network efficiency and longer battery life.

Key Features

5G Cellular
Built-in UNISOC V510 Modem-RF System, it has best 5G mobile network performance and works with integrated world-wide 5G to 2G multi-mode.

Wi-Fi 6 (802.11ax)
The revolutionary Wi-Fi technology with OFDMA and DL MU-MUMI, faster wireless line,more client connection, lower latency, best network efficiency.

Higher Wireless Capacity
Dual-band 4 spatial streams, the CPE outputs 1800Mbps wireless bandwidth (600 + 2475), makes you peace of mine while enjoy UHD videos, online games at the home rush hours. It’s the future-proof investment absolutely.

Hybrid MESH+ Networking
The CPE inherits the mesh technology and supports “wired / wireless” hybrid networking. It’s so convenient to cover all corners and dead-zones by adding one more MESH+ node (another series of router). it improves the deployments of wireless network and optimized the seamless feature.

5G Datasheet

• 5G Baseband: UNISOC V510 Modem-RF System
  Peak Downlink Rate:4.4Gbps Peak Uplink Rate:1500Mbps·
• 5G Network Modes: SA (standalone), NSA (non-standalone)
• 5G NSA Bands: N1/N3/N8/N28/N41/N77/N78/N79
• 5G SA Bands: N1/N3/N8/N28/N41/N77/N78/N79
• 5G SA Sub-6 DL2Gbps:UL 1Gbps
• 5G NSA Sub-6 DL 2.2 Gbps; UL 575 Mbps
• 5G SA Transmission Speed:2Gbps/1Gbps (up to ISPs)
• 5G NSA Transmission Speed:2.2Gbps/575Mbps (up to ISPs)

4G Datasheet

• LTE Category:Down Cat 16/ UP Cat 18
• LTE-FDD:B1/B2/B3/B5/B7/B8/B20/B28A/ B28
• LTE-TDD: B34/B38/B39/B40/B41
• LTE Down 4 × 4 MIMO:B1/B2/B3/B5/B7/B8/B20/B28A/ B28/B34/B38/B39/B40/B41
• WCDMA:B1/B2/B3/B4/B5/B8/B19
• LTE :Down 1.6 Gbps;UP 200 Mbps

WIFI6 Datasheet

WiFi 6(802.11ax)

• Working Radio: #1: 600Mbps @ 2.4GHz; #2: 2475Mbps @ 5.1-5.8GHz
• Coding Technology:1024-QAM / OFDMA
• Peak Connections:>100+ Clients
• Wi-Fi Standard Conformance:WiFi6 and 802.11ac / 802.11n backward
• Antenna: 8 external detachable high-performance antennas.

Data Switching

• Mobile 4G/5G Connection (Support APN)
• Giga Ethernet Connection
• MESH:MESH+ hybird
• 2.4G/5Ghz WiFi
• Advanced Firewall
• MAC Filter
• WiFi Sercurity
• VPN Passthrough and VPN Client (L2TP PPTP)
• IPV4/IPV6
• WEB / APP Mangement
• Firmware upgrade

Hardware Specification

• Chip:MT7981 +MT7976+MT7531
• Ethernet:1*1Gbps WAN,2*LAN 1Gbps
• 1* SIM Slot(Nano-SIM)
• Reset button
• MESH+ Button
• MESH+ LED Switch
• LED Indicator
  MESH+ Working Status (breathing light)
  4G Status
  5G Status
  WiFi Status
  Power Status
• General
  Power Consumption:<20W
  DC Power Supply: 12V/2A
  Working temperature:0℃~40℃, Storage temperature: -20℃~+70℃
  Humidity:5%~95%

Specification
