300Mbps Industrial Router 4g Chip MT7620A 4g Lte Wifi Router For Home
Product features
Specification
| Hardware specifications | ||
|
hardware system
|
master control | MT7620A |
| FLASH | 16MB | |
| DDR | 128MB | |
| 4G module | EC200A/EC20/EC25/EP06 | |
| Wireless parameters | Protocol standards | IEEE 802.11 b/ g/ n |
| Working frequency band | 2.4GHz:2412MHz~2472MHz | |
| Wireless rate | 300Mbps Max | |
| 4G rate |
LTE-FDD:Maximum downlink speed 150Mbps, maximum uplink speed 50Mbps LTE-TDD:Maximum downlink speed 130Mbps, maximum uplink speed 30Mbps |
|
| Transmission power | 18dBm Max | |
| physical interface | network interface |
1 10/100 Mbps RJ45 Ethernet WAN port 4 10/100 Mbps RJ45 Ethernet LAN ports |
| Power supply interface |
1 DC power port, supporting 12V DC power supply
|
|
| SIM card interface | 1 standard pop-up Mini SIM card slot | |
| Key switch | 1 RESET reset button | |
| PCI-E interface | 1 built-in PCI-E interface (optional or replaceable 4G modules of different brands) | |
| Antenna interface |
2 standard SMA interfaces for 4G antennas (external interface, interchangeable with different antennas) 2 WIFI antenna standard SMA interfaces (external interface, can replace different antennas) |
|
| pilot lamp | LED indicator light | Respectively POWER,4G,WIFI,WAN,LAN1,LAN2,LAN3, LAN4 |
| Power supply/power consumption | Power supply method |
DC 12V~1A power supply
|
| product accessories | main engine | Industrial grade intelligent 4G router host * 1 |
| DC adapter | DC 12V/1A | |
| antenna |
Two 5dBi high gain omnidirectional WIFI antennas Two 5dBi high gain omnidirectional 4G antennas |
|
| other | User manual * 1, warranty card * 1, certificate of conformity * 1 | |
| Appearance/Packaging | Product size |
External dimensions (length * width * height): 110mm * 90mm * 30mm (excluding antenna) Antenna height: 190mm |
| Appearance material | Iron shell, frosted surface | |
| Appearance color | Black (customizable appearance color) | |
| weight | 1.5kg | |
| other | Protection level | IP31,2KV lightning protection |
| Installation method | Desktop and wall mounted | |
| Usage environment |
Working temperature: -10 ℃~55 ℃ Storage temperature: -40 ℃~70 ℃ Working humidity: 10%~90% RH non condensing Storage humidity: 5%~95% RH non condensing |
|
